Integrierter FC-Glasfaserschnellsteckverbinder

Willkommen bei der Integrierter FC-Glasfaserschnellsteckverbinder Werk, Ihrem zuverlässigen Partner für hochwertige Glasfaserverbindungstechnologie. Jetzt kontaktieren!
Request a Quote

Details der produkte

  • Überblick
  • Product Description
  • Detailed Photos
  • Product Parameters
  • Packaging & Shipping
  • FAQ
  • Company Profile
Überblick

Grundlegende Informationen.

Modell Nr.
Schneller Anschluss
Anschlusstyp
Customization
Marke
3V-Tech
Material
Metall, Kunststoff
Bedingung
Neu
Name
Schneller Anschluss
Typ
ftth
Transportpaket
Standard Package
Warenzeichen
3V-Tech
Herkunft
China
HS-Code
3225961661
Produktionskapazität
500000PCS/Year

Produktbeschreibung

Product Description

Fiber Fast Connector is used for field assembled optical fiber connector ,widely used in fiber to the home (FTTH) access optical networks,to assemble with drop cable quickly.

Features

-Excellent Temperature stability

-Low insertion loss , high return loss

-Good repeatability and exchangeability

-Excellent mechanical endurance

-Customer defined specifications

-Compliant with Telcordia,TIA/EIA and IEC

Application

-Patch panels

-Distribution frames

-Maintenance or emergency restoration of fiber networks

-FTTH Outlets

-Connection at the desk for LAN environments
Detailed Photos

FC Embedded Type Fiber Optic Fast Connector

Product Parameters
Specification

Fast Connector Specification

Mode

SM

MM

Polish

UPC

APC

PC

Insertion Loss

Typical ≤0.3dB

≤0.5dB

Maximum ≤0.5dB

Return Loss

≥50dB

≥65dB

≥35dB

Interchangeability

≤0.2dB

Repeatability

≤0.1dB

Durability

≤0.2dB (500 times mating)

Tensile Strengh

≥50N

Temperature

≤0.2dB (-40+85 sustain 100 hours)

Humidity

≤0.2dB  (+25+65 93 R.H.100 hours)

Packaging & Shipping

FC Embedded Type Fiber Optic Fast Connector

FAQ

What Kind Of Services Can We Enjoy Buy From Suzhou 3V Technology Co., Ltd. ?
Arrange the shipping and delivery asap.
Inspect the quality carefully of your goods.
Good packaged avoid the damage of goods during shipping.
Make documents for you to do custom clearance,packing list and commercial invoice

Can We Get The Sample Order?
We welcome sample test and quality check.
Some products that are relatively small in size can be sent by express.
We need to charge the double sample fee, and don't worry the sample fee will refund you in your next further bulk order.

How Can You Guarantee The Quality Of The Products?
We have always placed great emphasis on quality control to make sure that excellent quality level is maintained.furthermore, every order will be checked out to guarantee the quantity and quality.

Which Logistics You Sent And How Long Can We Get The Goods?
It's up to your order quantities,we accept sea transportation and air transportation.

What Kinds Of Certificates Do You Have?
We have passed the inspection of GB,CE,UL,ROHS,3C etc,and Comprehensively guarantee the quality of the products.

Which Payment Method Do You Accept?
We accept T/T,Paypal and so on, any one method that we can negociate.

Company Profile

3V TECH was approved and registered by the Chinese Ministry of Commerce in 2011, located in Yangtze River Delta-Suzhou City, which is a famous land of milk and honey nearby Taihu Lake,and 1 hour briving to Shanghai

We specialize in producing of high-precision fiber capillary,fiber end-cap,V-groove,fiber array,customized pigtail&connectors and specialty optical fiber products,widely used in communications, lasing industry, medical devices and other industries.  Adhering to the concept of "leading technology" based on our experts with 16 years research experience in domestic professional research institution.so as to ensure the leading position in terms of special equipment and special manufacturing process.Our products are highly praised by customers in China and abroad as good quality and price,like Europe, America, South Korea, Japan.

Enterprise Tenet: Professional; Honest; thanks; Win-win

We hope more opportunities of cooperation with you and initiate a splendid tomorrow together.
